NomeTreeshear Vosch
CodiceTreeshear
TipologiaVosch
Dettagli
250S :
Carrier (tons) :
2,-8
Weight (kg) :
230
Pressure cut(bar) :
250
Pressure rotate (bar) :
170
Oil flow cut (l/min) :
60
Oil flow rotate (l/min) :
40
Opening max (mm) :
250
Cuts (mm) :
140
Cutting force (kN) :
125
Rotation motors :
1
Rotation:
360°
Measurements(mm) :
1500x490x350
Ulteriori Informazioni
TWO STEP WORK PROCESS
This treeshear doesn´t cut until the tree or branch is secured, because of the step-valve. Hold the branch or tree before cutting and safely lay the felled tree afterwards.
BE IN CONTROL OF 360°
Our tree shears can be endlessly rotated. The 360° maneuvering possibility enables you to position the shear in every possible way. Especially beneficial while debranching and for safely laying the felled tree of branch after cutting.
SHEER FORCE
Regardless of whether you want to cut branches, bushes, brush or whole trees, our tree shear does the job. Cutting till a diameter of 450 mm (18″) and safely laying the cutted material afterwards.
OPTIONS
All tree shears are standard equipped with a single rotation motor, good for 5000 Nm torque. The largest model is ready for an additional rotation motor to reach a total torque of 10.000 Nm. The high speed valve can be mounted to increase speed during closing. Optional hydraulically actuated locking pin.
